Multi-Lane Speed Radar MR62
 |
Speed range: 5–200km/h
keyword：
Millimeter wave radar series
whatsapp：
+86 152 0048 8528
INTRODUCTION
MR62 is the latest multi-lane speed measuring radar introduced by Nanoradar Science and Technology. It adopts 60GHz ISM frequency band, FM continuous wave system and multi-antenna transceiver technology, and can realize multi-lane (1 ~ 4 lanes) multi-target (32 targets) speed measurement with a detection distance of 90 meters. It can support lane division, distinguish direction and destination, install compensation for lanes, and the speed measurement range and accuracy meet the national measurement standards.
Features：
- 60GHz ISM frequency range
- Supports two-way multi-lane multi-target trajectory tracking and detection, with 1-4 lanes horizontally and 90 meters vertically
- Multi-target real-time speed monitoring, with a maximum of 32 targets and a speed measurement range of 5 ~ 200km/h
- Customized data output
- All-day and all-weather work, including rain, snow, fog, strong wind, ice, dust, etc
- Supports TTL serial port communication, customizes communication protocol, supports radar parameter configuration, and supports configuration of detection area
Application：
- Multi-lane speed measurement, roadside illegal parking
SPECIFICATIONS
| System performance | |||
Transmit frequency | 61.2~61.5GHz | Capture rate | ≥99% >95%（traffic jam） |
| Modulating waveform | FMCW | Overspeed capture rate | ≥95% |
| Interface | TTL serial port | ||
| Measuring performance | |||
| Distance range | 2~90m | Cover the lane | 1~4 lanes(can distinguish lanes) |
| Speed range | 5~200km/h | Multi-target monitoring | 32 |
| Beam width | 56°×17° | ||
Operating conditions | |||
| Operating voltage | 5V DC | Power consumption | ≤2.5W |
Operating temperature | -40~+60℃ | Operating humility | 5%RH-90%RH |
Storage temperature | -40~+85℃ | ||
| Housing | |||
| Overall dimensions (LxWxH) | 48×52mm(module) | Weight | ＜10g(module) |
ADVANTAGES
 | Multi-Lane Coverage with Direction Discrimination Accurate speed measurement capable of automatically detecting vehicle speeds across 1–4 lanes. Supports lane division to distinguish between incoming and outgoing traffic, outputting speed, distance, angle, and target energy values. |
 | Customizable and User-Friendly Supports customized communication protocols based on user requirements. Allows configuration of radar parameters, detection zones, and tailored data output. |
Strong Environmental Adaptability Unaffected by adverse conditions such as light, dust, rain, snow, fog, or sandstorms. Provides 24/7 real-time monitoring of road sections. |
APPLICATION
With the surge in urban vehicle ownership, traditional video surveillance faces bottlenecks such as low visibility and missed multi-target detection.Data shows that traffic accidents during severe weather increase by 2.3 times compared to normal conditions, highlighting the urgent need for all-weather intelligent sensing devices to ensure smooth road network operations.
