Traffic Flow Radar TCM873

80GHz | Range: 500m
Speed range: -300 to +300km/h

keyword：

Millimeter wave radar series

Classification：

Traffic Radar

Tel：

+86-731-88939916

whatsapp：

+86 152 0048 8528

E-mail：

INTRODUCTION

TCM873 is an 80 GHz traffic flow statistical millimeter wave radar module independently developed by Hunan Nanoradar Technology Co., Ltd. The module can provide multi-target tracking information between large, medium and small vehicles, non-motorized vehicles and pedestrians traveling in both directions within a range of 500 meters(max), including real-time information such as ID, distance, speed, azimuth and status of all targets. At the same time, it also supports traffic flow statistics, which can output information such as vehicle spacing, occupancy, queue length, congestion and so on. Among them, the accuracy of congestion flow statistics reaches 90%, and the accuracy of flat peak flow statistics reaches 95%.

Features：

Super sensing, stable and accurate, 80GHz frequency band,detection distance of 500m(max),, 80 ° wide beam, covering 10 lanes, can detect 512 targets
Radar vision integration, support two levels of data depth fitting, space-time synchronization, support GPS, PTP timing
Software-defined radar, flexible adaptation of intersection, road section, high-speed three modes
Simulate the real scene, close to the actual application, configured with channelization, green isolation belt and live function
Strong adaptability, easy to deal with complex environment, four levels of sensitivity can be adjusted to reduce the false alarm rate; wrong frequency design can avoid interference between radars, 7 × 24h all-weather real-time protection, adapt to rain, snow, fog, haze, dust and other bad weather

Application：

High-speed traffic monitoring, intersection monitoring, intersection detection and other application scenarios.

Multi-Lane Speed Enforcement Radar TSC224

Traffic Flow Radar MR76S

SPECIFICATIONS

System performance
Transmit frequency	80.00GHz	Transmitting power	29.8dBm
Modulating waveform	FMCW	Refresh rate	About 80ms
Interface	RS485/Ethernet port
Measuring performance
Distance range	1.2~500m@0°	Cover the lane	10 lanes
Speed range	-300~+300km/h	Multi-target monitoring	512
Beam width	LRR:30°×11°;SRR:80°×26°
Operating conditions
Operating voltage	9~32V DC	Power consumption	12W
Operating temperature	-40~+70℃	Storage temperature	-40~+85℃
Protection rating	IP67
Housing
Overall dimensions (LxWxH)	185×176×44.9mm

ADVANTAGES

APPLICATION

Nanoradar Empowered Radar-Vision Integrated System for Precision Signal Control and Efficient Traffic Flow Detection

With the surge in urban vehicle ownership, traditional video surveillance faces bottlenecks such as low visibility and missed multi-target detection.Data shows that traffic accidents during severe weather increase by 2.3 times compared to normal conditions, highlighting the urgent need for all-weather intelligent sensing devices to ensure smooth road network operations.
