Traffic Flow Radar TCR300
Speed range：0~250km/h
keyword：
Millimeter wave radar series
whatsapp：
+86 152 0048 8528
INTRODUCTION
TCR300 is a compact 80GHz high-performance traffic flow monitoring radar, which uses the frequency difference between the transmitted radio wave and the echo to accurately measure the speed, distance, angle and other information of the target. TCR300 adopts many advanced technologies such as DBF digital beam synthesis, MIMO virtual synthetic aperture, far and near dual-mode detection, etc. It has the characteristics of high precision, easy debugging, high stability, etc. The radar can detect 4~6 lanes and 128 targets at the same time, with a maximum detection distance of 280 meters, and can be widely used in application scenarios such as highway flow monitoring and intersection monitoring.
Features：
- Two-way multi-lane multi-target trajectory tracking and detection, software real-time online simulation, lateral 4-6 lanes, longitudinal 280 meters
- Multi-target real-time speed monitoring, with a maximum of 128 targets and a speed measurement range of 0~250km/h
- Multi-row virtual coil setting, coil size and position software can be adjusted, and real-time output of vehicle presence information
- Multi-section lane-dividing statistical data output, including traffic, speed, occupancy rate, headway, maximum queue length, etc
- Supports traffic incident detection, including slow congestion, retrograde, abnormal parking, lane change, too close to the car, etc
- Customized data output
- All-day and all-weather work, including rain, snow, fog, strong wind, ice, dust, etc
- Supports RJ45 Ethernet interface and RS485 serial interface, switching value
Application：
- Traffic flow statistics, Whole process monitoring of bridges and tunnels, Safety distance control snapshot, Traffic cooperative safety early warning
SPECIFICATIONS
| System performance | |||
Transmit frequency | 80.00~81.00GHz | Transmitting power | 29.8Hz |
| Modulating waveform | FMCW | Refresh rate | 80ms |
| Interface | RJ45/RS485 | ||
| Measuring performance | |||
| Distance range | LRR:1.2~280m@0°;MRR:1.2~50m@±45° | Cover the lane | 4~6 lanes |
| Speed range | 0~250km/h | Multi-target monitoring | 128 |
| Beam width | LRR:22°×13°;MRR:90°×13° | ||
Operating conditions | |||
| Operating voltage | 12V DC | Power consumption | ≤4W |
Operating temperature | -40~+70℃ | Storage temperature | -40~+85℃ |
| Protection rating | IP66 | ||
| Housing | |||
| Overall dimensions (LxWxH) | 149.5×126×45mm | Weight | 650g |
ADVANTAGES
Frequency Isolation for Absolute Anti-Interference Utilizes the 80GHz band, physically isolated from the 77GHz band (used by automotive radars), effectively preventing interference from vehicle radars. | |
Dual-Beam Detection with Multi-Lane Coverage Featuring near-and-far dual-beam detection, it achieves a measurement range of 1.2–280m: Long-Range Beam: Extended detection capability for distant targets. Short-Range Beam: Wide coverage for multi-lane target detection. Supports 4–6 lanes, enabling precise distance measurement, speed detection, and positioning for up to 128 targets. | |
 | Advanced Algorithm for Precise Detection Effectively resolves issues like large vehicle target splitting. Eliminates false alarms and missed detections for low-speed targets. Filters out false alerts caused by wind-induced movements in roadside greenery through advanced algorithms, ensuring precise detection. |
APPLICATION
VIDEO
DOWNLOAD
FAQ
TCR300 | Installation Guidelines
Front-mounted: LED facing downward, Height: 6-8m, Pitch angle: ≤3°, Coverage: 6 lanes (max range: 280m), Multi-vehicle range: 180-220m
Side-mounted:LED facing downward, Height: 6-8m, Pitch angle: ≤3°, Coverage: 3 lanes (max range: 280m)
TCR300 | Indicator Lights
Red: Power ON (steady)
Yellow: Target detection (blinking)
Blue: Network connection active
TCR300 | Failed upgrade
The host computer upgrade is not successful, after restart, you can use the web to upgrade.
