Perimeter Radar NSR120
+
  • Perimeter Radar NSR120

Perimeter Radar NSR120


80GHz | Range 120m, 22°

keyword:

Millimeter wave radar series

Classification:

whatsapp:

+86  152 0048 8528

E-mail:

INTRODUCTION


SPECIFICATIONS


ADVANTAGES


APPLICATION


图片名称

VIDEO


DOWNLOAD


NSR120 Brochure

220.5KB

NSR120 User Manual

1.2MB

NSR120 White Paper

766.9KB

< 1 >

FAQ


NSR120 | Installation Guide

Important: Do not install upside down. Correct installation:The indicator lights are located at the lower right corner when facing the radar, the arrow on the back of the radar indicates the upward-facing side.

Based on actual testing: Installation azimuth should be determined according to the key security zone requirements. Recommended installation height: 1.5m-3m. Lateral detection range: ±1.5m to ±3m (measured from centerline to both sides). Target detection distance: 120m (final settings subject to actual conditions).

For side-mounted installation: Horizontal azimuth angles: Short-range: ±45°, Long-range: ±11°, Radar performance will be limited and cannot achieve optimal performance. Side mounting is not recommended for customers.

NSR120 | Radar Indicator Lights

Power-on status:

Red light (power indicator): Steady on

Blue light (network connection indicator): Steady on

When detecting target speed:

Green light (operation status indicator): Illuminates

NSR120 | During indoor pedestrian testing, why are pedestrian targets difficult to detect, with multipath and split false targets occurring?

When testing with the radar connected to the host PC indoors: Pedestrian targets are difficult to detect. Multipath and split false targets appear. Technical explanation: Indoor testing is prone to multipath effects. These issues do not occur in outdoor field tests.
