Ground Surveillance Radar NSR100W
keyword：
Millimeter wave radar series
whatsapp：
+86 152 0048 8528
INTRODUCTION
NSR100W intelligent monostatic radar for regional security, is one k-band radar sensor developed by Hunan Nanoradar Science and Technology Co., Ltd., which aims at the application of regional security, and is one of the NSR series of high-end products. NSR100W utilizes single pulse technology and low-power FMCW modulation technology, with high-precision angular resolution, very low-speed measurement capabilities and precise ranging capability. It can get rid of the interference of trees by signal processing and pattern recognition. Therefore it is a highly intelligent and precise security alarm equipment.
Features：
- Work in 24GHz Band for the detection of moving targets
- Able to detect the moving targets in extremely slow speed and filter the interference of plants and trees
- Able to detect azimuth/range information about object
- Protection class: IP66
- With Ethernet interface and PoE
- RoHS compliant
Application：
- Regional security
SPECIFICATIONS
| System performance | |||
Transmit frequency | 24.00~24.25GHz | Transmitting power | 20dBm |
| Modulating waveform | FMCW | Update rate | 8Hz |
| Interface Specifications | |||
| Communication Interfaces | RJ45(10M/100M,PoE)/RS485 | Alarm Interfaces | Relay outputs (0.5A/125V AC)*2 Opto-isolated IO outputs (isolation voltage: 2500V AC)*2 IO input*1 |
| Supported network protocals | HTTP, DNS, NTP, TCP, UDP, DHCP, ARP, SSH | ||
| Measuring performance | |||
| Distance range | 150m | Range accuracy | ±0.5m |
| Speed range | 0.5m/s~30m/s | Angle measuring accuracy | ±1° |
| Beam width | 90°×13° | ||
Operating conditions | |||
| Operating voltage | 12V DC | Power consumption | 8W |
Operating temperature | -40~+75℃ | Storage temperature | -40~+85℃ |
| Protection rating | IP66 | ||
| Housing | |||
| Overall dimensions (LxWxH) | 194×158×49mm | ||
ADVANTAGES
 | Multi-Target Detection, No Escape Employs MIMO/TBD/JDPA and Doppler sensing technologies to identify intruders moving slowly (e.g., crawling), quickly (e.g., running), or crouching, regardless of posture or position within the detection zone. Supports simultaneous tracking of up to 32 targets. |
 | Interference Filtering, Reduced False Alarms Filters out environmental and animal interference (e.g., birds, trees) using target characteristic parameters, minimizing false and missed alarms. |
 | Resilient in Harsh Environments IP66-rated for high waterproof and dustproof performance, resistant to shocks and drops. Operates reliably in extreme conditions such as glare, dust, rain, snow, fog, and sandstorms. |
 | WEB Management, Open Architecture Unified management via WEB interface, supports GPS map import, zone configuration, real-time monitoring, and recording/playback. The open architecture allows flexible expansion into multi-level networked systems. |
APPLICATION
Successful Application Case of Millimeter Wave Radar in Lock Gate Systems
Common anti-entrapment and traffic efficiency solutions: visual cameras, infrared beams, LiDAR, etc. Considering performance, reliability, and cost, MMW radar + vision offers the best cost-efficiency. 70% reduction in gate collisions/entrapments, saving >8 million CNY in repairs. 25% higher traffic efficiency: Average transit time shortened from 40 to 30 minutes. 50% fewer manual inspections, cutting O&M costs by 20%.
3D Millimeter Wave Radar Helps State Grid Prevent External Damage in Transmission Corridors
External damage incidents to transmission lines have become a major threat to the reliability and safety of the power grid.There is an urgent need for technological innovations in detection capabilities, application strategies, and management models to enhance the precision, timeliness, and effectiveness of monitoring construction machinery hazards. This will fundamentally eliminate potential risks and ensure the safe operation of transmission lines.
VIDEO
DOWNLOAD
FAQ
NSR200/NSR100W/NSR300W | Pre-installation Testing Environmental Requirements
Different products have different testing scenario requirements:
NSR200 (Perimeter Type): Requires an area with ~5m width and ≥20m length.
NSR100W (Regional Type): Requires an open area of 100M-150M.
NSR300W (Regional Type): Requires an open area of 300M-450M.
NSR200/NSR100W/NSR300W | Troubleshooting False Alarms at Fixed Positions
After confirming no interfering objects at alarm locations:
If the alarm point has large road signs or reflective objects (metal/glass), adjust the angle or remove them.
Set filtering zones for specific points to eliminate false alarms.
Configuration path: Web → Calculation → Range Parameters
NSR200/NSR100W/NSR300W | No Targets Detected During Operation
Ping the radar IP to confirm successful connection.
Log in to the radar web interface and check indicator lights to confirm if the radar entered protection mode.
Check the X-axis and Y-axis ranges in the host software to ensure targets aren't being filtered.
Observe X/Y-axis values in the web preview to confirm targets aren't being web-filtered.
Check if parameters were not reset after upgrading from an old version. Clear browser cache.
If unresolved, contact technical support to check radar logs via XSHELL for error messages.
